Hand Pallet Truck


HAND PALLET TRUCK
yuan.gif (523 bytes) A built overload valve and totally sealed hydraulic pump,seals of hydraulic pump are
     imported form Germany
yuan.gif (523 bytes) Heavy duty one piece"c" section forks for the greatest strength and durability
yuan.gif (523 bytes) Two nylon entry and exit rollers prevent physical exertion of the operator and protect
     load wheels and pallet
yuan.gif (523 bytes) Load roller:Single or Tandem Nylon, Polyurethane
yuan.gif (523 bytes) Steering wheel:Nylon, Polyurethane, Rubber
yuan.gif (523 bytes) Special fork length are available:800,900,950,1000,1100,1300,1500,2000mm
yuan.gif (523 bytes) Materials and specification are subject to change without ontice



Model

CBG 2000 CBG 2500
Capacity                                (kg) 2000 2500
Max.Fork Height                    (mm) 190/200
Min.Fork Height                     (mm) 75/85
Fork Length                           (mm) 1150 1220
Width Overall Forks               (mm) 520/550 กก
Individual Fork Width             (mm) 160
Load Roller Diameter            (mm) 74/80 Nylon,polyurethane
Steering Wheel Kiameter     (mm) 180/200 Nylon,polyurethane,Rubber
Net Weight                            (kg) 80 85
Quantities/20'Container          (pcs) 180 144
